21IA4T15GA2-ABS34-BDA08024CS-C003-32-6
21IA4T15GA2
Pneumatically operated seat valve Series 21IA.GA; NO; Body Stainless steel 1.4408; Seal PTFE; Female thread; For gaseous media and liquids; Medium temperature -40...+180°C; G 1/2"; DN 15mm; Operating pressure 0-25bar; Control pressure 5-10bar
ABS34
Mounted pilot valve Series ABS; Silencer; Suitable for Pneumatically operated seat valves Series 21IA; 3/2-way solenoid valve (31A3AV20); Standard coil BDA; Connector size 32mm
BDA08024CS
Coil Type BDA; Standard; Connector size 32mm; Voltage 24VDC
C003-32-6
Connector; Connector size 32mm; Standard; Voltage 0...250VAC/DC
Country of origin: Italy
Weight: 1.813 Kg
Short Itemnumber: 21IA4T15GA2ABS34BDA08024CSC003326
21IA4T15GA2
pneumatically operated seat valve series 21IA.GA; NO; body stainless steel AISI 316; seal PTFE; female thread; for gaseous media and liquids; medium temperature -40...+180°C; G 1/2"; DN 15mm; operating pressure 0-25bar; control pressure 5-10bar
ABS34
mounted pilot valve series ABS; silencer; suitable for pneumatically operated seat valves series 21IA; 3/2-way solenoid valve (31A3AV20); standard coil BDA; connector size 32mm
BDA08024CS
coil type BDA; standard; connector size 32mm; voltage 24VDC
C003-32-6
connector; connector size 32mm; standard; voltage 0...250VAC/DC
