Flanged ball valve with pneumatic actuator BA043-100-D0-A

Flanged ball valve with pneumatic actuator BA043-100-D0-A

Flanged ball valve with pneumatic actuator Series BA043-A; ATEX II 2 G/D; Flange PN16; Body Steel; Ball 1.4301; Seals PTFE/FKM; Double acting actuator ATEX II 2 G/D c T6; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 100mm; Length 152mm; Actuator PAD100

Intrastat No.: 84818081
Country of origin: Italy

Weight: 41.42 Kg
Short Itemnumber: BA043100D0A

flanged ball valve with pneumatic actuator series BA043-A; ATEX II 2 G/D; flange PN16; body steel; ball AISI 304; seals PTFE/FKM; double acting actuator ATEX II 2 G/D c T6; control pressure 5,5...8bar; medium temperature -20...+160°C; pressure range 0...16bar; nominal diameter 100mm; length 152mm; actuator PAD100

On request

DN
- 100 mm
Length
- 152 mm
Design
- ATEX
Actuator
- PAD100

This combination does not exist.

Availability:

See availability

Technical specifications

Pressure range	0...16bar
DN	100 mm
Length	152 mm
Design	ATEX

Data sheets, drawings and CAD files

Pressure range	0...16bar
DN	100 mm
Length	152 mm
Design	ATEX

BA043-100-D0-A

Documents

1 Documents

English

Declarations of Conformity

1

PDF
Druckluftdrehantrieb · EN
ATEX - certificate 32 KB Updated 13/06/2026

View Download

Flanged ball valve BA043-100-L-A

BA043-100-L-A x 1.0 Pcs

Flanged ball valve BA043-100-L-A

Flanged ball valve Series BA043-L-A; ATEX II 2 G/D; Flange PN16, Full bore; Body Steel; Ball 1.4301; Seals PTFE/FKM; Pressure range 0...16bar; Medium temperature -20...+160°C; Nominal diameter 100mm; Length 152mm

Pneumatic actuator PAD100

PAD100 x 1.0 Pcs

Pneumatic actuator PAD100

Pneumatic actuator Series PAD; ATEX II 2 G/D; Double acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Diameter 100mm; Flange ISO5211 F07/F10; Female square 17mm; Torque at 5,5bar 150Nm

RI3004 x 1.0 Pcs

RI3004

Mounting bracket For Ball valve; F10/F07-F10; Bolt 17-18
