BA080-20-H8

BA080-20-H8

ball valve with hydraulic actuator; housing, ball brass; seals PTFE/FKM/EPDM; double acting actuator; control pressure 20...120bar; medium temperature -20...+160°C; RP 2"; nominal diameter 50mm; pressure range 0-40bar; length 138mm; actuator HAD28

Intrastat No.: 84818081
Country of origin: Italy
Weight: 10.98 Kg
Short Itemnumber: BA08020H8
https://www.stasto.hu/web/image/product.template/176633/image_1920?unique=f96ddcc

ball valve with hydraulic actuator; housing, ball brass; seals PTFE/FKM/EPDM; double acting actuator; control pressure 20...120bar; medium temperature -20...+160°C; RP 2"; nominal diameter 50mm; pressure range 0-40bar; length 138mm; actuator HAD28

999.999,00 € 999999.0 EUR 999.999,00 €

On request

  • Brand

This combination does not exist.

Availability:
See availability
Contact Us

Technical specifications

Pressure range 0-40bar
Brand STASTO
Pressure range 0-40bar
Brand STASTO
Ball valve made of brass 2500-2"
2500-2" x 1.0 Pcs
Ball valve made of brass 2500-2"
Ball valve made of brass Series 2500; Bare shaft; Full bore; Female thread; Seal PTFE/FKM/EPDM; Medium temperature -20...+160°C; RP 2"; Nominal diameter 50mm; Pressure range 0...40bar; Length 138mm; Flange ISO5211 F05; Square 11mm
HAD28 x 1.0 Pcs
HAD28
Hydraulic actuator; Double acting; Rotation angle 90°; Operating pressure range 10...120bar; Diameter 28mm; Flange ISO5211 F07
04808007001 x 1.0 Pcs
04808007001
Mounting bridge; Zinc plated steel; F05/F07-F05; Height 60mm
A4/309/98 x 1.0 Pcs
A4/309/98
Power transmission pin for butterfly valves DN65/80, actuator SR100
