Flanged ball valve with pneumatic actuator Series BAEB, BAEA Store
  1. Products
  2. Armatures
  3. Ball valves - automatically operated
  4. Flanged ball valves - pneumatically operated
  5. Flanged ball valve with pneumatic actuator Series BAEB, BAEA
  6. BAEA-065-SSTV-S0-ABS53-C001-03-C002-31-6
BAEA-065-SSTV-S0-ABS53-C001-03-C002-31-6
Flanged ball valve with pneumatic actuator BAEA-065-SSTV-S0
Flanged ball valve with pneumatic actuator BAEA-065-SSTV-S0
2.133,20 €
2.133,20 €
BAEA-065-SSTV-S0-ABS53-C001-03-C002-31-LV-2
BAEA-065-SSTV-S0-ABS53-C001-03-C002-31-LV-2
2.277,72 €
2.277,72 €

BAEA-065-SSTV-S0-ABS53-C001-03-C002-31-6

BAEA-065-SSTV-S0
Flanged ball valve with pneumatic actuator Series BAEB, BAEA; Fire-safe; TA-Luft; Length According to EN558−1R27; Body, Ball 1.4408; Seals PTFE/Graphoil/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 65mm; Pressure range 0-16bar; Flange PN16; Length 170mm; Actuator PAS1155
ABS53
Mounted pilot valve Series ABS; NAMUR; Silencer; Standard coil C001; Connector size 22mm; 3/2-way-NAMUR-Solenoid valve (NM32W1S-PR); Actuator PAS052-270
C001-03
Coil Type C001; Connector size 22mm; Voltage 24VDC / 48V/50-60Hz
C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC

Intrastat No.: 84818081
Country of origin: Italy
Weight: 28.83 Kg
Short Itemnumber:BAEA065SSTVS0ABS53C00103C002316
https://www.stasto.hu/web/image/product.template/199396/image_1920?unique=7caf835

BAEA-065-SSTV-S0
flanged ball valve with pneumatic actuator series BAEB, BAEA; fire-safe; TA-Luft; length according to EN558−1R27; body, ball AISI 316; seals PTFE/Graphoil/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; nominal diameter 65mm; pressure range 0-16bar; flange PN16; length 170mm; actuator PAS1155
ABS53
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 3/2-way-NAMUR-solenoid valve (NM32W1S-PR); actuator PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC

2.272,69 € 2272.69 EUR 2.272,69 €

ár kérésre

  • Valve interface Namur
  • DN
  • Length
  • Flange
  • Connector size
  • Design
  • Voltage
  • Pressure range
  • Coil
  • Actuator
  • Actuator 2

This combination does not exist.

Availability:
Contact Us
dimension
Valve interface Namur 1/4"
DN 65 mm
Length 170 mm
Flange PN16
Designs
Connector size 22
design
Design Standard
Electrical key figures
Voltage 24VDC / 48V/50-60Hz
pressure
Pressure range 0...16 bar
characteristics
Coil C001
Actuator PAS1155

Data sheets, Instructions, 3D-files and Certificates...
