HAC001

STASTO Combination consists of:
3-fold solenoid valve unit
3 Stk.5/2-way valve; pilot-operated; pressure range 2,5...9bar; actuation electrical/spring; nominal diameter 8mm; flow rate 1300Nl/min; incl. coil and connector 24VDC;
inlet base plate 12mm;
outlets valves 8mm
fully assembled and tested

Intrastat No.: 84812090
Country of origin:
Italy Made in Europe
Weight:
1.18 Kg
Short Itemnumber:
HAC001
https://www.stasto.hu/web/image/product.template/225421/image_1920?unique=05f8c09

STASTO Combination consists of:
3-fold solenoid valve unit
3 Stk.5/2-way valve; pilot-operated; pressure range 2,5...9bar; actuation electrical/spring; nominal diameter 8mm; flow rate 1300Nl/min; incl. coil and connector 24VDC;
inlet base plate 12mm;
outlets valves 8mm
fully assembled and tested

567,30 € 567.3 EUR 567,30 €

ár kérésre

excl. tax
  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element
  • Brand

This combination does not exist.

Availability:
See availability

Technical specifications

Brand STASTO
Brand STASTO
KME314 x 1.0 Pcs
Manifold sub-base KME314
Manifold sub-base Series K; For way-valves Series K5., K6., K9.; Anodized aluminum; Number of valves 3; Pressure connection 3/8"; Exhaust ports 3/8"; Valve size 1/4"
K52W1014 x 3.0 Pcs
5/2-way valve K52W1014
5/2-way valve Series K5.W; Pilot-operated; Pressure range 2,5...9bar; Actuation Electrical/spring; Type of coil CS; Connector size 16mm; Connection 1/4"; Nominal diameter 8mm; Flow rate 1300Nl/min; Suitable silencer alle
6-14423-0525 x 3.0 Pcs
Connector 6-14423-0525
Connector; Connector size 16mm; With integrated LED-yellow and VDR; Voltage 24VAC/DC
CS02400 x 3.0 Pcs
Coil CS02400
Coil Type CS; Connector size 16mm; Voltage 24VDC
TH50-38-N-0 x 3.0 Pcs
Plug screw TH50-38-N-0
Plug screw Series TH50; Nickel plated brass; With o-ring NBR; Cylindrical thread; Hexagon socket; Thread 3/8"
SLN-M38-RB x 2.0 Pcs
Silencer SLN-M38-RB
Silencer Series SLN-RB; Sinterbronze; Thread Steel copper plated; Operating pressure Max. 16bar; Connection 3/8"; Length 36mm
