IWTS003

Name: IWTS003
Brand: STASTO
SKU: IWTS003

STASTO combination consisting of: valve island 4HF25CS-DD-DD-D-S0R 10-way, 3/2-way solenoid valve, NC voltage 24VDC fully assembled with all fittings, throttles and filter regulator

Weight: 3.52 Kg
Short Itemnumber: IWTS003

On request

Function
- -
Design
- -
Actuator
- -
Brand
- STASTO

This combination does not exist.

Availability:

Specifications
Spare Parts

Brand

STASTO

TH60-14-12-N x 1.0 Pcs

Female to male reducer adapter TH60-14-12-N

Female to male reducer adapter Series TH60; Nickel plated brass; Cylindrical thread; Female thread 1/4"; Male thread 1/2"

SLB-14-B x 1.0 Pcs

Silencer bushing SLB-14-B

Silencer bushing Series SLB; Sinterbronze; Operating pressure Max. 10bar; Connection 1/4"; Length 19mm

TH50-14-N-0 x 2.0 Pcs

Plug screw TH50-14-N-0

Plug screw Series TH50; Nickel plated brass; With o-ring NBR; Cylindrical thread; Hexagon socket; Thread 1/4"

TH50-12-N-0 x 1.0 Pcs

Plug screw TH50-12-N-0

Plug screw Series TH50; Nickel plated brass; With o-ring NBR; Cylindrical thread; Hexagon socket; Thread 1/2"

TH38C-14-38-N x 1.0 Pcs

Reduction hex nipple TH38C-14-38-N

Reduction hex nipple Series TH38C; Nickel plated brass; Conical thread; Thread 1/4"; Thread 3/8"

FR-38-20-08-R-PE-SS x 1.0 Pcs

Filter regulator FR-38-20-08-R-PE-SS

Filter regulator Series FR01/FR; Relieving; Drain valve Semi-automatic; Pressure range 0,5...8bar; Filter element 20µm; Plastic bowl with protection cage; Connection 3/8"; Flow at 6,3bar/Δp=1bar 2100Nl/min; Max. inlet pressure 12,5bar

3830-3/8" x 1.0 Pcs

Ball valve made of brass 3830-3/8"

Ball valve made of brass Series 3830; Mini type; Female thread; Seals PTFE/NBR; Medium temperature -20...+90°C; Turning handle Polyamide; Pressure range 0...10bar; G 3/8"; Nominal diameter 8mm; Length 41mm
