K0N002

K0N002

STASTO Combination
fully assembled and tested
consists of:
1 x S-23-X: blow gun without nozzle; operating pressure 2...6bar; material plastic; continous air control by hand lever
1 x S-26-SNPS: standard air-nozzle with protection shield; blowing force at a distance of 100mm at 6bar 1,4N; air consumption at 6bar 120Nl/min; noise at a distance of 1m at 6bar 82dB(A)
1 x PR92-14-4: pressure regulator; fixed pressure set; inlet pressure max. 12bar; flow at 12bar/Δp=0,5bar 350 Nl/min; pressure 4bar
1 x SC12-08-12-N-0: straight male stud fitting nickel plated brass; pressure -1…18bar; cylindrical thread; diameter 8/6mm; thread 1/2"
1 x SC12C-08-14-N: straight male stud fitting; nickel plated brass; pressure -1…25bar; conical thread; diameter 8/6mm; thread 1/4"
2 x SC32-08-N-YA: swivel nut; nickel plated brass; pressure -1…25bar; with antikink-spiral; diameter 8/6mm
5m: C-SSP08: spiral hose; material polyamide; multiplier for operating pressure 30°C = 0,87 / 80°C = 0,43; temperature range -60...130°C; colour blue; diameter outside 8mm; diameter inside 6mm; diameter spiral 96mm; operating pressure at 23°C 20bar

Intrastat No.: 84242000
Country of origin: Italy
Weight: 0.451 Kg
Short Itemnumber: K0N002
https://www.stasto.hu/web/image/product.template/226222/image_1920?unique=15fb532

STASTO Combination
fully assembled and tested
consists of:
1 x S-23-X: blow gun without nozzle; operating pressure 2...6bar; material plastic; continous air control by hand lever
1 x S-26-SNPS: standard air-nozzle with protection shield; blowing force at a distance of 100mm at 6bar 1,4N; air consumption at 6bar 120Nl/min; noise at a distance of 1m at 6bar 82dB(A)
1 x PR92-14-4: pressure regulator; fixed pressure set; inlet pressure max. 12bar; flow at 12bar/Δp=0,5bar 350 Nl/min; pressure 4bar
1 x SC12-08-12-N-0: straight male stud fitting nickel plated brass; pressure -1…18bar; cylindrical thread; diameter 8/6mm; thread 1/2"
1 x SC12C-08-14-N: straight male stud fitting; nickel plated brass; pressure -1…25bar; conical thread; diameter 8/6mm; thread 1/4"
2 x SC32-08-N-YA: swivel nut; nickel plated brass; pressure -1…25bar; with antikink-spiral; diameter 8/6mm
5m: C-SSP08: spiral hose; material polyamide; multiplier for operating pressure 30°C = 0,87 / 80°C = 0,43; temperature range -60...130°C; colour blue; diameter outside 8mm; diameter inside 6mm; diameter spiral 96mm; operating pressure at 23°C 20bar

76,80 € 76.8 EUR 76,80 €

ár kérésre

  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element

This combination does not exist.

Availability:
Contact Us

Share

No Specifications
Blow gun S-23-X
S-23-X x 1.0
Blow gun S-23-X
Blow gun Series S-23; Without nozzle; Nozzle connection M12x1,25; Operating pressure 2...6bar; Material Plastic; Continous air control by hand lever; Connection type mit Anschluss 1/4" innen
Add to Cart
Spiral hose C-SSP08
C-SSP08 x 5.0
Spiral hose C-SSP08
Spiral hose Series C-SSP; Material Polyamide; Multiplier for operating pressure 30°C = 0,87 / 80°C = 0,43; Without fittings; Working length = 0,5 x effective stretched length; Temperature range -60...130°C; Colour Blue; Diameter Outside 8mm; Diameter Inside 6mm; Diameter Spiral 96mm; Operating pressure at 23°C 20bar
