KN0206

Name: KN0206
Brand: STASTO
SKU: KN0206
Price: 604.6 EUR
Availability: InStock

STASTO Combination
Fully assembled and tested
Incl. Cylinder NWT-50-500;
Incl. E52W2S018 5/2-way valve Bistable, G-50/63 Rod clevis; Voltage 24VDC

Intrastat No.: 84123100
Country of origin: Italy
Weight: 4.303 Kg
Short Itemnumber: KN0206

STASTO Combination
fully assembled and tested
incl. cylinder NWT-50-500;
incl. E52W2S018 5/2-way valve bistable, G-50/63 rod clevis; voltage 24VDC

604,60 € 604.6 EUR 604,60 €

Connection
- -
Dimension
- -
Function
- -
Max. inlet pressure
- -
Flow at 6bar/Δp=1bar
- -
Filter element
- -

This combination does not exist.

Availability:

Add to cart

Specifications
Spare Parts

No Specifications

PC60-50-500 x 1.0

Profile magnetic cylinder PC60-50-500

profile magnetic cylinder series PC60; according to ISO 15552, VDMA; double acting; pressure range 0,5...10bar; adjustable cushions; diameter 50mm; stroke 500mm; piston rod thread M16x1,5; connection 1/4"; push force at 6 bar 1178N

Add to Cart

G-50-63 x 1.0

Rod clevis G-50-63

Rod clevis Series G; For cylinder; Thread M16x1,5; Diameter Series NWT, RWS, ACMT-ISO 50, 63mm; Diameter Series NSKU-M 80mm

Add to Cart

TH61C-18-N x 1.0

Elbow adapter Male thread TH61C-18-N

Elbow adapter Male thread Series TH61; Nickel plated brass; Thread R 1/8"; Thread konisch

Add to Cart

PI16-08-18-N-0-360 x 1.0

Swivel male elbow PI16-08-18-N-0-360

Swivel male elbow Series PI16-360; Nickel plated brass; Cylindrical thread; Diameter 8mm; Thread 1/8"

Add to Cart

PI16-08-14-N-0-360 x 1.0

Swivel male elbow PI16-08-14-N-0-360

Swivel male elbow Series PI16-360; Nickel plated brass; Cylindrical thread; Diameter 8mm; Thread 1/4"

Add to Cart

TH60C-18-14-N x 1.0

Female to male reducer adapter TH60C-18-14-N

Female to male reducer adapter Series TH60C; Nickel plated brass; Conical thread; Female thread 1/8"; Male thread 1/4"

Add to Cart

TH16C-18-N x 1.0

Elbow adapter Male thread/Female thread TH16C-18-N

Elbow adapter Male thread/Female thread Series TH16C; Nickel plated brass; Conical thread; Thread 1/8"

Add to Cart

TH12-18-N-L16 x 1.0

Extension 1/8"

Extension Series TH12; Nickel plated brass; Cylindrical thread; Thread 1/8"

Add to Cart

TH12-18-N-L36 x 1.0

Extension TH12-18-N-L36

Extension Series TH12; Nickel plated brass; Cylindrical thread; Thread 1/8"

Add to Cart

RSS-1/8" x 2.0

Throttle RSS-1/8"

Throttle Series RSS; Silencer; Self blocking; Connection 1/8"; DN 4,5mm

Add to Cart

VNPR2 x 2.0

Magnetic switch VNPR2

Magnetic switches Series VN/RV; Function Reed; LED; Temperature range -20...+85°C; Suitable for Cylinder ISO 6432, Compact cylinder, Cylinder ISO 15552, Cylinder Series AW2, RWS, CRW, Round cylinder, Gripper Diameter 20+32mm; Connection Kabel; Diameter of cylinder 12...200mm; U 3...48 AC/DCV; Current 0,1A; S 6VA; Cable length 3m

Add to Cart

PA-8/6-BK-1 x 1.0

Plastic hose PA-8/6-BK-1

Plastic hose Series PA; Material Polyamide; Multiplier for operating pressure 30°C = 0,87 / 80°C = 0,43; Vacuum -0,87bar; Temperature range -60...130°C; Outside diameter 8mm; Inside diameter 6mm; Operating pressure at 23°C 20bar; Colour schwarz

Add to Cart

E52W2S018 x 1.0

5/2-way valve E52W2S018

5/2-way valve Series E5.; Pilot-operated; Pressure range 1,5...10bar; Actuation Electrical/electrical; Standard coil C001; Connector size 22mm; Connection 1/8"; Nominal diameter 6mm; Flow rate 650Nl/min

Add to Cart
