STASTO Combination 7-fold

STASTO Combination 7-fold

STASTO Combination
Fully assembled and tested
Solenoid valve unit; 7-fold; Consists of:
3 x 5/3-way valve; K53W2S618; Actuation Electrical/electrical; Central position Closed;
3 x 5/2-way valve K52W1018; Into 3/2-way-Design; NC; Actuation Electrical/spring;
1 x Free space for solenoid valve;
Voltage 24VDC; Incl. coil And Connector LED ; Connections Push-in fitting 8mm; Pressure inlet 12mm

Intrastat No.: 84812090
Country of origin: Italy
Weight: 1.582 Kg
Short Itemnumber: KÜN007
https://www.stasto.hu/web/image/product.template/189027/image_1920?unique=458f784

STASTO Combination
fully assembled and tested
solenoid valve unit; 7-fold; consists of:
3 x 5/3-way valve; K53W2S618; actuation electrical/electrical; central position closed;
3 x 5/2-way valve K52W1018; into 3/2-way-design; NC; actuation electrical/spring;
1 x free space for solenoid valve;
voltage 24VDC; incl. coil and connector LED ; connections push-in fitting 8mm; pressure inlet 12mm

1.112,20 € 1112.2 EUR 1.112,20 €

ár kérésre

  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element

This combination does not exist.

Availability:
Contact Us

Share

No Specifications
Manifold sub-base KME718
KME718 x 1.0
Manifold sub-base KME718
Manifold sub-base Series K; For way-valves Series K5., K6., K9.; Anodized aluminum; Number of valves 7; Pressure connection 1/4"; Exhaust ports 1/4"; Valve size 1/8"
Add to Cart
5/3-way valve K53W2S618
K53W2S618 x 3.0
5/3-way valve K53W2S618
5/3-way valve Series K5.W; Pilot-operated; Pressure range 3...9bar; Actuation Electrical/electrical; Type of coil CS; Connector size 16mm; Connection 1/8"; Nominal diameter 6mm; Central position gesperrt; Flow rate 552Nl/min; Suitable silencer SLN-RB
Add to Cart
5/2-way valve K52W1018
K52W1018 x 3.0
5/2-way valve K52W1018
5/2-way valve Series K5.W; Pilot-operated; Pressure range 2,5...9bar; Actuation Electrical/spring; Type of coil CS; Connector size 16mm; Connection 1/8"; Nominal diameter 6mm; Flow rate 730Nl/min; Suitable silencer SLN-RB
Add to Cart
6-14423-0525
6-14423-0525 x 9.0
6-14423-0525
Connector; Connector size 16mm; With integrated LED-yellow and VDR; Voltage 24VAC/DC
Add to Cart
Plug screw 1/8"
TH50-18-N-0 x 3.0
Plug screw 1/8"
Plug screw Series TH50; Nickel plated brass; With o-ring NBR; Cylindrical thread; Hexagon socket; Thread 1/8"
Add to Cart
Silencer SLS-M14-NS
SLS-M14-NS x 2.0
Silencer SLS-M14-NS
Silencer Series SLS-NS; Operating pressure Max. 12bar; Connection 1/4"; Length 18mm; Body Messing vernickelt; Screen Edelstahl
Add to Cart
