MAP002
STASTO AutomationPackage
Completely picked and checked
Consists of
1x RE63-12-0,05/9
Proportional pressure regulating valve Series RE63; Electronic control; Input signal 0...10V; Outlet signal 4...20mA; Maximum inlet pressure 10Bar; Connection 1/2"; Exhaust port 1/2"; Adjustment range 0,05...9bar; Flow at 6bar/Δp=1bar 6000Nl/min
1x PP110-I2-PS
5/2-way valve Series PP110; According to ISO 5599/1; Pressure range 4...10bar; Actuation Pneumatic/internal air; Size ISO2; DN 13mm; Flow rate 2200Nl/min
1x PS137-I3
5/2-way valve Series PS137; Bistable; According to ISO 5599/1; Pilot-operated; Pressure range 3...10bar; Actuation Electrical/electrical; Standard coil C001; Connector size 22mm; Size ISO3; Flow rate 5500Nl/min
2x C001-03
Coil Type C001; Connector size 22mm; Voltage 24VDC / 48V/50-60Hz
2x C002-31-LV-2
Connector; Connector size 22mm; With integrated LED-yellow and VDR; Voltage 24VAC/DC
Short Itemnumber: MAP002
STASTO AutomationPackage
Completely picked and checked
Consists of
1x RE63-12-0,05/9
Proportional pressure regulating valve Series RE63; Electronic control; Input signal 0...10V; Outlet signal 4...20mA; Maximum inlet pressure 10Bar; Connection 1/2"; Exhaust port 1/2"; Adjustment range 0,05...9bar; Flow at 6bar/Δp=1bar 6000Nl/min
1x PP110-I2-PS
5/2-way valve Series PP110; According to ISO 5599/1; Pressure range 4...10bar; Actuation Pneumatic/internal air; Size ISO2; DN 13mm; Flow rate 2200Nl/min
1x PS137-I3
5/2-way valve Series PS137; Bistable; According to ISO 5599/1; Pilot-operated; Pressure range 3...10bar; Actuation Electrical/electrical; Standard coil C001; Connector size 22mm; Size ISO3; Flow rate 5500Nl/min
2x C001-03
Coil Type C001; Connector size 22mm; Voltage 24VDC / 48V/50-60Hz
2x C002-31-LV-2
Connector; Connector size 22mm; With integrated LED-yellow and VDR; Voltage 24VAC/DC
| Brand | STASTO |
