SE02-D15-SV51-01

SE02-D15-SV51-01

Pneumatically operated seat valve; NC; Body Stainless steel 1.4408; Seal FKM; Butt weld ends; For liquids; Closing against flow; Medium temperature -30...+200°C; DN 15mm; Operating pressure 0-22bar; Control pressure 3,5-10bar; Diameter Actuator 50mm; Special version: High temperature design; Incl. 3/2-way pilot valve 24VDC

Intrastat No.: 84818079
Country of origin: Germany
Weight: 1.44 Kg
Short Itemnumber: SE02D15SV5101
https://www.stasto.hu/web/image/product.template/140938/image_1920?unique=b5fa7f5

pneumatically operated seat valve; NC; body stainless steel AISI 316; seal FKM; butt weld ends; for liquids; closing against flow; medium temperature -30...+200°C; DN 15mm; operating pressure 0-22bar; control pressure 3,5-10bar; diameter actuator 50mm; special version: high temperature design; incl. 3/2-way pilot valve 24VDC

749,20 € 749.2 EUR 749,20 €

ár kérésre

    This combination does not exist.

    Availability:
    Contact Us

    Share

    No Specifications
    No spare parts are available for this product.
    Accessory Products
    AC-SE02-D15-SV51-01
    AC-SE02-D15-SV51-01
    AC-SE02-D15-SV51-01
