SE11-12-RT81-ABS31-C001-22-C002-31-LV-1

SE11-12-RT81-ABS31-C001-22-C002-31-LV-1

SE11-12-RT81
Pneumatically operated seat valve Series SE11-RT; NO; 3-way-type; Body Bronze; Seal PTFE; Female thread; For gaseous media and liquids; Medium temperature -30...+170°C; RP 1/2"; DN 15mm; Operating pressure 0-16bar; Control pressure 2,3-5bar; Diameter Actuator 80mm
ABS31
Mounted pilot valve Series ABS; Silencer; Suitable for Pneumatically operated seat valves Series SE, Pinch valves Series PI03, Series PI04; 3/2-way solenoid valve (31A3AV20); Standard coil BDA; Connector size 32mm; Actuator 80 mm/125 mm
C001-22
Coil Type C001; Connector size 22mm; Voltage 230V/50-60Hz
C002-31-LV-1
Connector; Connector size 22mm; With integrated LED-yellow and VDR; Voltage 230VAC/DC

Druckgesteuertes Sitzventil Serie SE11-RT
Intrastat No.: 84818079
Country of origin: Germany Made in Europe
Weight: 0.72 Kg
Short Itemnumber: SE1112RT81ABS31C00122C00231LV1
https://www.stasto.hu/web/image/product.template/209856/image_1920?unique=d58514c

SE11-12-RT81
pneumatically operated seat valve series SE11-RT; NO; 3-way-type; body bronze; seal PTFE; female thread; for gaseous media and liquids; medium temperature -30...+170°C; RP 1/2"; DN 15mm; operating pressure 0-16bar; control pressure 2,3-5bar; diameter actuator 80mm
ABS31
mounted pilot valve series ABS; silencer; suitable for pneumatically operated seat valves series SE, pinch valves series PI03, series PI04; 3/2-way solenoid valve (31A3AV20); standard coil BDA; connector size 32mm; actuator 80 mm/125 mm
C001-22
coil type C001; connector size 22mm; voltage 230V/50-60Hz
C002-31-LV-1
connector; connector size 22mm; with integrated LED-yellow and VDR; voltage 230VAC/DC

888,00 € 888.0 EUR 888,00 €

ár kérésre

excl. tax
  • Female thread
  • DN
  • Diameter Actuator
  • Connector size
  • Design
  • Voltage
  • Voltage type
  • Operating pressure
  • Control pressure
  • Coil
  • Actuator
  • Medium temperature

This combination does not exist.

Availability:
See availability
Contact Us

Technical specifications

Female thread RP 1/2"
DN 15 mm
Diameter Actuator 80 mm
Operating pressure 0...16 bar
All specifications (8)
Documents
Data sheets, drawings and CAD files
Female thread RP 1/2"
DN 15 mm
Diameter Actuator 80 mm
Operating pressure 0...16 bar
Control pressure 2,3...5 bar
Medium temperature -30...+170 °C
Voltage 230V/50-60Hz
Design With integrated LED-yellow and VDR
