STASTO Combination
Fully assembled and tested
1 x NSYS3D8620P; Enclosure; Steel
2 x V32V1P6M8; 3/2-way valve; Actuation Pneumatic/spring; Connection 1/8"; DN 6mm; Function NC; Flow rate 650Nl/min
2 x RE03-14VH-0,1/3-MA-PR; Precision pressure regulator Series Modul RE03-PR; Relieving; Inlet pressure Max. 16bar; Constant air consumption 2,6l/min; Connection 1/4"; Flow at 6bar/Δp=1bar 1500Nl/min; Pressure range 0,1-3bar
2 x VCML32018; 3/2-way valve; NC; Connection 1/8"; DN 6mm; Actuation Handhebel/rastend; Flow rate 650Nl/min
1 x FI03-14; Filter; Drain valve Semi-automatic; Inlet pressure Max. 16bar; Plastic bowl; Filter element 5µm; Connection 1/4"; Flow at 6bar/Δp=1bar 1000Nl/min
1 x VCML32014; 3/2-way valve; NC; Connection 1/4"; DN 8mm; Actuation Handhebel/rastend; Flow rate 1080Nl/min
2 x V32V1P6M8; 3/2-way valve; Actuation Pneumatic/spring; Connection 1/8"; DN 6mm; Function NC; Flow rate 650Nl/min
1 x AT01-1-11; Compressed air tank; Air pressure connection 1/2"; Capacity 1l
Intrastat No.: 84812090
Country of origin: Italy
Weight: 34.882 Kg
Short Itemnumber: T0P010
Country of origin: Italy
Weight: 34.882 Kg
Short Itemnumber: T0P010
STASTO Combination
fully assembled and tested
1 x NSYS3D8620P; enclosure; steel
2 x NWT32-90-SEP; profile magnetic cylinder series NWT-SEP; according to ISO 15552, VDMA; single acting, backside spring; pressure range 0,5...10bar; adjustable cushions; diameter 32mm; stroke 90mm;
2 x V32V1P6M8; 3/2-way valve; actuation pneumatic/spring; connection 1/8"; DN 6mm; function NC; flow rate 650Nl/min
2 x RE03-14VH-0,1/3-MA-PR; precision pressure regulator series Modul RE03-PR; relieving; inlet pressure max. 16bar; constant air consumption 2,6l/min; connection 1/4"; flow at 6bar/Δp=1bar 1500Nl/min; pressure range 0,1-3bar
2 x VCML32018; 3/2-way valve; NC; connection 1/8"; DN 6mm; actuation Handhebel/rastend; flow rate 650Nl/min
1 x FI03-14; filter; drain valve semi-automatic; inlet pressure max. 16bar; plastic bowl; filter element 5µm; connection 1/4"; flow at 6bar/Δp=1bar 1000Nl/min
1 x VCML32014; 3/2-way valve; NC; connection 1/4"; DN 8mm; actuation Handhebel/rastend; flow rate 1080Nl/min
2 x V32V1P6M8; 3/2-way valve; actuation pneumatic/spring; connection 1/8"; DN 6mm; function NC; flow rate 650Nl/min
1 x AT01-1-11; compressed air tank; air pressure connection 1/2"; capacity 1l
Technical specifications
| Brand | STASTO |
|---|
| Brand | STASTO |
TH26C-12-N
x 1.0 Pcs
T-adapter Male thread TH26C-12-N
T-adapter Male thread Series TH26; Nickel plated brass; Thread R 1/2"; Thread konisch
TH13-14-12-N
x 1.0 Pcs
Female to female reducer coupling TH13-14-12-N
Female to female reducer coupling Series TH13; Nickel plated brass; Thread 1/4"; Thread 1/2"
TH50-12-N-0
x 1.0 Pcs
Plug screw TH50-12-N-0
Plug screw Series TH50; Nickel plated brass; With o-ring NBR; Cylindrical thread; Hexagon socket; Thread 1/2"
TH16C-14-N
x 3.0 Pcs
Elbow adapter Male thread/Female thread TH16C-14-N
Elbow adapter Male thread/Female thread Series TH16C; Nickel plated brass; Conical thread; Thread 1/4"
TH61C-14-N
x 1.0 Pcs
Elbow adapter Male thread TH61C-14-N
Elbow adapter Male thread Series TH61; Nickel plated brass; Thread R 1/4"; Thread konisch
PI24-04-14-N-0-360
x 1.0 Pcs
Male stud branch tee swivel PI24-04-14-N-0-360
Male stud branch tee swivel Series PI24-360; Nickel plated brass; Cylindrical thread; Diameter 4mm; Thread 1/4"
TH35-18-N
x 1.0 Pcs
Banjo TH35-18-N
Banjo Series TH35; Nickel plated brass; Female thread; Diameter 1/8"mm; Thread 1/8"
PI12-04-06-N
x 1.0 Pcs
Reduction PI12-04-06-N
Reduction Series PI12; Nickel plated brass; Diameter 1 4mm; Diameter 2 6mm
FC04-18-W
x 2.0 Pcs
Banjo flow control valve 1/8"
Banjo flow control valve Series FC04; Without banjo; Actuation Slotted screw/Knurled screw fixable; Connection 1/8"
SLB-18-B
x 2.0 Pcs
Silencer bushing SLB-18-B
Silencer bushing Series SLB; Sinterbronze; Operating pressure Max. 10bar; Connection 1/8"; Length 17mm
TH16C-18-N
x 6.0 Pcs
Elbow adapter Male thread/Female thread TH16C-18-N
Elbow adapter Male thread/Female thread Series TH16C; Nickel plated brass; Conical thread; Thread 1/8"
TH20-18-N
x 2.0 Pcs
Cross piece Female thread TH20-18-N
Cross piece Female thread Series TH20; Nickel plated brass; Thread 1/8"
TH38C-18-N
x 4.0 Pcs
Hex nipple TH38C-18-N
Hex nipple Series TH38C; Nickel plated brass; Conical thread; Thread 1/8"
SLS-M18-NS
x 9.0 Pcs
Silencer SLS-M18-NS
Silencer Series SLS-NS; Operating pressure Max. 12bar; Connection 1/8"; Length 15mm; Body Messing vernickelt; Screen Edelstahl
TH59C-18-14-N
x 1.0 Pcs
Female to male reducer adapter TH59C-18-14-N
Female to male reducer adapter Series TH59C; Nickel plated brass; Conical thread; Male thread 1/8"; Female thread 1/4"
PI12-04-18-N-0
x 9.0 Pcs
Straight male stud fitting PI12-04-18-N-0
Straight male stud fitting Series PI12; Nickel plated brass; Cylindrical thread; Diameter 4mm; Thread 1/8"
MV48-06-06-3
x 1.0 Pcs
3/2-way valve MV48-06-06-3
3/2-way valve Series MV48; Pressure range 0...15bar; Operating force at 6 bar: 12N; Actuation Rocker arm/bistable; NC/NO; Connection 6mm; Flow rate 185Nl/min
MV46-00-18-3
x 1.0 Pcs
3/2-way valve MV46-00-18-3
3/2-way valve Series MV46; Pressure range 0...15bar; Operating force at 6 bar: 12N; Flow rate 235Nl/min; Actuation Rocker arm/bistable; NC; Connection 1/8"
SLS-M14-NS
x 1.0 Pcs
Silencer SLS-M14-NS
Silencer Series SLS-NS; Operating pressure Max. 12bar; Connection 1/4"; Length 18mm; Body Messing vernickelt; Screen Edelstahl
PI24-04-18-N-0-360
x 1.0 Pcs
Male stud branch tee swivel PI24-04-18-N-0-360
Male stud branch tee swivel Series PI24-360; Nickel plated brass; Cylindrical thread; Diameter 4mm; Thread 1/8"
DI02-14-4-18
x 1.0 Pcs
Distributor DI02-14-4-18
Distributor Series DI02; Material Anodized aluminum; Outlet thread 1/8"; Connecting thread 1/4"; Outlets One-sided; Distance of outlets 30mm; Number of outlets 4
TH38C-18-14-N
x 1.0 Pcs
Reduction hex nipple TH38C-18-14-N
Reduction hex nipple Series TH38C; Nickel plated brass; Conical thread; Thread 1/8"; Thread 1/4"
TH24C-14-N
x 1.0 Pcs
T-adapter Female thread/Female thread/Male thread TH24C-14-N
T-adapter Female thread/Female thread/Male thread Series TH24C; Nickel plated brass; Conical thread; Thread 1/4"
PI24-06-14-N-0-360
x 1.0 Pcs
Male stud branch tee swivel PI24-06-14-N-0-360
Male stud branch tee swivel Series PI24-360; Nickel plated brass; Cylindrical thread; Diameter 6mm; Thread 1/4"
SLN-M14-RB
x 4.0 Pcs
Silencer SLN-M14-RB
Silencer Series SLN-RB; Sinterbronze; Thread Steel copper plated; Operating pressure Max. 16bar; Connection 1/4"; Length 28mm
V32V1P6M8
x 4.0 Pcs
3/2-way valve V32V1P6M8
3/2-way valve Series V3; Pressure range 2,7...10bar; Actuation Pneumatic/spring; Connection 1/8"; DN 6mm; Function NC; Flow rate 650Nl/min
RE33-14VH-0,5/10-MA
x 4.0 Pcs
RE33-14VH-0,5/10-MA
Pressure regulator; Relieving; Inlet pressure Max. 16bar; Connection 1/4"; Flow at 6bar/Δp=1bar 1500Nl/min; Pressure range 0,5-10bar; Manometer in the handwheel
VCML32018
x 2.0 Pcs
3/2-way valve VCML32018
3/2-way valve Series VCML; Pressure range 0...10bar; NC; Connection 1/8"; DN 6mm; Actuation Handhebel/rastend; Flow rate 650Nl/min
FI03-14
x 1.0 Pcs
Filter FI03-14
Filter Series Modul FI03; Drain valve Semi-automatic; Inlet pressure Max. 16bar; Plastic bowl; Filter element 5µm; Connection 1/4"; Flow at 6bar/Δp=1bar 1000Nl/min
VCML32014
x 1.0 Pcs
3/2-way valve VCML32014
3/2-way valve Series VCML; Pressure range 0...10bar; NC; Connection 1/4"; DN 8mm; Actuation Handhebel/rastend; Flow rate 1080Nl/min
AT01-1-11
x 1.0 Pcs
Compressed air tank AT01-1-11
Compressed air tank Series AT01; Operating pressure Max. 11bar; According to 2014/68 EU; Air pressure connection 1/2"; Capacity 1l
MV23-00-14
x 3.0 Pcs
Check valve MV23-00-14
Check valve Series MV23; Axial type; Female thread; Nickel plated brass; Pressure range 0,2...10bar; Connection 1/4"; Flow rate 1500Nl/min; Length 42,5mm
RSS-1/8"
x 2.0 Pcs
Throttle RSS-1/8"
Throttle Series RSS; Silencer; Self blocking; Connection 1/8"; DN 4,5mm
K32P1918
x 1.0 Pcs
3/2-way valve K32P1918
3/2-way valve Series K3.P; Pressure range 3,1...9bar; Actuation Pneumatic/spring; Connection 1/8"; DN 6mm; Function NO; Flow rate 690Nl/min; Suitable silencer SLN-RB
TH60-18-14-N
x 1.0 Pcs
Female to male reducer adapter TH60-18-14-N
Female to male reducer adapter Series TH60; Nickel plated brass; Cylindrical thread; Female thread 1/8"; Male thread 1/4"
TH60-14-12-N
x 1.0 Pcs
Female to male reducer adapter TH60-14-12-N
Female to male reducer adapter Series TH60; Nickel plated brass; Cylindrical thread; Female thread 1/4"; Male thread 1/2"
PI16-04-18-N-0-360
x 14.0 Pcs
Swivel male elbow PI16-04-18-N-0-360
Swivel male elbow Series PI16-360; Nickel plated brass; Cylindrical thread; Diameter 4mm; Thread 1/8"
VCMT32018
x 1.0 Pcs
3/2-way valve VCMT32018
3/2-way valve Series VCMT; Pressure range 0...10bar; NC; Connection 1/8"; DN 6mm; Actuation Taste/rastend; Flow rate 650Nl/min
PI27-06-N
x 1.0 Pcs
Bulkhead fitting PI27-06-N
Bulkhead fitting Series PI27; Nickel plated brass; Diameter 6mm
PI21-04-18-N-0-360
x 1.0 Pcs
Male stud branch tee swivel PI21-04-18-N-0-360
Male stud branch tee swivel Series PI21-360; Nickel plated brass; Cylindrical thread; Diameter 4mm; Thread 1/8"
PI16-04-14-N-0-360
x 8.0 Pcs
Swivel male elbow PI16-04-14-N-0-360
Swivel male elbow Series PI16-360; Nickel plated brass; Cylindrical thread; Diameter 4mm; Thread 1/4"
TH38C-14-B-Z
x 2.0 Pcs
Detachable hex nipple TH38C-14-B-Z
Detachable hex nipple Series TH38C; Brass; Conical thread; Metal sealing; Thread 1/4"; Thread 1/4"
PA-4/2,5-BU-1
x 14.0 m
Plastic hose PA-4/2,5-BU-1
Plastic hose Series PA; Material Polyamide; Multiplier for operating pressure 30°C = 0,87 / 80°C = 0,43; Vacuum -0,87bar; Temperature range -60...130°C; Outside diameter 4mm; Inside diameter 2,5mm; Operating pressure at 23°C 32bar; Colour Blue
PA-4/2,5-BK-1
x 50.0 m
Plastic hose PA-4/2,5-BK-1
Plastic hose Series PA; Material Polyamide; Multiplier for operating pressure 30°C = 0,87 / 80°C = 0,43; Vacuum -0,87bar; Temperature range -60...130°C; Outside diameter 4mm; Inside diameter 2,5mm; Operating pressure at 23°C 32bar; Colour Black
VCML52018
x 1.0 Pcs
5/2-way valve VCML52018
5/2-way valve Series VCML; Pressure range 0...10bar; Connection 1/8"; DN 6mm; Actuation Handhebel/rastend; Flow rate 650Nl/min
K52W2018-CS02400-C001-31-LVCV30-2
x 1.0 Pcs
K52W2018-CS02400-C001-31-LVCV30-2
K52W2018
5/2-way valve Series K5.W; Pilot-operated; Pressure range 1,5...9bar; Actuation Electrical/electrical; Type of coil CS; Connector size 16mm; Connection 1/8"; Nominal diameter 6mm; Flow rate 730Nl/min; Suitable silencer SLN-RB
CS02400
Coil Type CS; Connector size 16mm; Voltage 24VDC
C001-31-LVCV30-2
Connector; Connector size 16mm; mit eingebauter LED, VDR und PVC-Kabel (3 m); Voltage 24VAC/DC
MDI03-14
x 1.0 Pcs
T-distributor MDI03-14
T-distributor Series Modul MDI03; Inlet pressure Max. 16bar; 4 Outlets; Connection 1/4"; Outlets 4 x 1/4"; Flow rate 2500Nl/min; DN 6mm
PDS-1-008-M-2-1
x 1.0 Pcs
Pressure switch PDS-1-008-M-2-1
Pressure switch Series PDS; Change-over contact; Diaphragm NBR; 250VAC/6A, 24VDC/3A; Female thread 1/4"; Application: Air, Water, Hydraulic oil; Protection class IP65; Connector size 32mm; Range of adjustment 0,5…8bar; Overpressure protection 60bar; Hysteresis range 0,13…0,9bar
TH38C-14-N
x 3.0 Pcs
Hex nipple TH38C-14-N
Hex nipple Series TH38C; Nickel plated brass; Conical thread; Thread 1/4"
FC04-18-W-SLB-18-B
x 4.0 Pcs
Banjo flow control valve FC04-18-W-SLB-18-B
FC04-18-W
Banjo flow control valve Series FC04; Without banjo; Actuation Slotted screw/Knurled screw fixable; Connection 1/8"
SLB-18-B
Silencer bushing Series SLB; Sinterbronze; Operating pressure Max. 10bar; Connection 1/8"; Length 17mm
PI27-04-N
x 6.0 Pcs
Bulkhead fitting PI27-04-N
Bulkhead fitting Series PI27; Nickel plated brass; Diameter 4mm
SLN-M14-BB
x 1.0 Pcs
Silencer SLN-M14-BB
Silencer Series SLN-BB; Sinterbronze; Thread Brass; Operating pressure Max. 16bar; Connection 1/4"; Length 32mm
TH13-14-B
x 1.0 Pcs
Female to female coupling TH13-14-B
Female to female coupling Series TH13; Brass; Thread 1/4"
