Ball valves - automatically operated

[KL08] Tortellino Tészta és Édesipari Kft.
BA033-34N-S0
Ball valve with pneumatic actuator; Female thread; Body, Ball 1.4401; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; 3/4"NPT; Nominal diameter 20mm; Pressure range 0…40bar; Length 76mm; Actuator PAS0635
BA153-112-S0
Ball valve with pneumatic actuator; Body, Ball Brass; Seals PTFE/FKM/EPDM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; 11/2" NPT; Nominal diameter 40mm; Pressure range 0-40bar; Length 114mm; Actuator PAS0635
BAC1-005-SSTV-D0A
Ball valve with pneumatic rotary actuator 52 double-acting, body and ball 1.4401, thread i/i ATEX anti-static connection RP3/4"
BA593-114-B
ball valve made of stainless steel; bare shaft; female thread; full bore; housing AISI 316L polished; ball AISI 316L; seals PTFE/Kalrez; medium temperature -40...+160°C; G 11/4"; nominal diameter 32mm; pressure range 0…64bar; length 92mm; flange ISO5211 F05; square 14mm
BA057-12-S0
Ball valve with pneumatic actuator; Female thread; Body Zinc plated steel; Ball Steel; Seals POM/NBR; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+100°C; G 1/2"; Nominal diameter 13mm; Pressure range 0-500bar; Length 85mm; Actuator PAS0855
BA057-12-T0
Ball valve with pneumatic actuator; Female thread; Body Zinc plated steel; Ball Steel; Seals POM/NBR; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+100°C; G 1/2"; Nominal diameter 13mm; Pressure range 0-500bar; Length 85mm; Actuator PAS0855; Safety position NO
BAH1-004-UCPN-T0
Ball valve with pneumatic actuator; Female thread; Body Zinc plated steel; Ball Steel; Seals POM/NBR; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+100°C; G 1/2"; Nominal diameter 13mm; Pressure range 0-500bar; Length 85mm; Actuator PAS0855; Safety position NO
BA364-12-D0B-01
Ball valve with pneumatic actuator; Female thread; Body, Ball 1.4401; Seals PTFE-Reinforced with carbographite/EPDM; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -40...+160°C; Ambient temperature -30...+85°C; RP 1/2"; Nominal diameter 15mm; Pressure range 0...64bar; Length 65mm; Actuator PAD052-L
BA034-25-S0
Ball valve with pneumatic actuator Series BA034-S0; Butt weld ends; Body, Ball 1.4401; Seals PTFE-reinforced/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 25mm; Pressure range 0-40bar; Length 92mm; Actuator PAS0635
BA043-50-PG-A
Flanged ball valve with electrical actuator; Flange PN16; Body Steel; Ball 1.4301; Seals PTFE/FKM; Medium temperature -10...+160°C; DN 50mm; Pressure range 0-16bar; Length 82mm; For a maximum of 100 operations a day; 2 potential-free contacts for end position feedback; Incl. manual emergency override; Protection class IP68; ATEX II2GD ExdIIBT6Gb ExtbIIICT80°CDb; Incl. Accumulator for safety position; Operating time 20s; Voltage 100-240V/50-60Hz, 100-350VDC
BA592-15-B
flanged ball valve; bare shaft; flange PN40; full bore; housing AISI 316L polished; ball AISI 316L; seals PTFE/Kalrez; medium temperature -40...+160°C; nominal diameter 15mm; length 115mm; pressure range 0...40bar; flange ISO5211 F03; square 9mm
BA080-12-S0-01
Ball valve with pneumatic actuator; Body, Ball Brass; Seals PTFE/FKM/EPDM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; RP 1"; Nominal diameter 25mm; Pressure range 0-40bar; Length 90mm; Actuator PAS0525; Incl. ABS53-24VDC-UL Approval
RKH-G1/2-13-4465-DFA
High pressure ball valve; Female thread; Body, Ball 1.4571; Seals PEEK/FKM; For liquids; Medium temperature -20...+100°C; G 1/2"; Nominal diameter 13mm; Pressure range 0-400bar; For mounting an actuator
BA080-12-T0-01
Ball valve with pneumatic actuator; Body, Ball Brass; Seals PTFE/FKM/EPDM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; RP 1"; Nominal diameter 25mm; Pressure range 0-40bar; Length 90mm; Actuator PAS0525; Incl. ABS53-24VDC-UL Approval; Safety position Open
BA137-25-PQ-A
Flanged ball valve with electrical actuator; Flange PN16; Body, Ball 1.4401; Seals PTFE/FKM; Medium temperature -20...+160°C; ATEX-Antistatic; DN 25mm; Pressure range 0-16bar; Length 46mm; Voltage 100-240V/50-60Hz; 100-350VDC; Operating time 7s; Actuator VRX25-0Q7-Q17-01, ATEX II2GD ExdIIBT6Gb ExtbIIICT80°CDb; Incl. Accumulator for safety position
BAB1-006-BLTV-S1
Ball valve with pneumatic actuator; Body, Ball Brass; Seals PTFE/FKM; Single acting actuator; Control pressure 3...8bar; Medium temperature -20...+160°C; RP 1"; Nominal diameter 25mm; Pressure range 0-40bar; Length 90mm; Actuator PAS0751
BAB1-005-BLTV-S001
Ball valve with pneumatic actuator Series BAB1; Body, Ball Brass; Seals PTFE/FKM/EPDM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; RP 3/4"; Nominal diameter 20mm; Pressure range 0-40bar; Length 76mm; Actuator PAS0525; Incl. ABS53-24VDC; Mounted pilot valve; NAMUR; Silencer; Standard coil C001; Connector size 22mm; 3/2-way-NAMUR-Solenoid valve (NM32W1S-PR)
BADA-025-IITV-D0
Ball valve with pneumatic rotary actuator 52 double-acting, body and ball 1.4301, flange PN 16 connection DN25
BAT1-004-TSTV-D0
Ball valve with pneumatic rotary actuator 52 double-acting, ball valve 1.4401, 3-way T-port version connection RP1/2"
BA080-20-D4
Ball valve with pneumatic actuator; Body, Ball Brass; Seals PTFE/FKM/EPDM; Double acting actuator; Control pressure 5...8bar; Medium temperature -20...+160°C; RP 2"; Nominal diameter 50mm; Pressure range 0-40bar; Length 138mm; Actuator PAD063
