Ball valves - automatically operated

[KL08] Tortellino Tészta és Édesipari Kft.
BA400-15-B-A
Flanged ball valve; ATEX II 2G/D T4; Bare shaft; 3-way-type; Full bore; Body 1.4404 Polished; Ball 1.4404; Seals PTFE/EPDM; Sealing on three ports; Medium temperature -20...+150°C; Nominal diameter 15mm; Pressure range 0...40bar; Flange PN40; Length 130mm; Ball T; Flange ISO5211 F03; Square 9mm
BA400-15-S0-A
Flanged ball valve with pneumatic actuator; ATEX II 2G/D T4; 3-way-type; Sealing on three ports; Body 1.4404 Polished; Ball 1.4404; Seals PTFE/EPDM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+150°C; Nominal diameter 15mm; Length 130mm; Pressure range 0...40bar; Flange PN40; Actuator PAS0755; Ball T
BA402-15-T0-A
Flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; Body, Ball 1.4401; Seals PTFE/Carbographite; With o-ring From EPDM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -40...+160°C; Nominal diameter 15mm; Pressure range 0-40bar; Flange PN40; Length 35mm; Actuator PAS0635; Safety position NO
BA411-10-B
Ball valve made of stainless steel; Bare shaft; Female thread; Full bore; Body 1.4404 Polished; Ball 1.4404; Seals Fibre-glass-reinforced PTFE/FKM; Medium temperature -20...+170°C; G 1"; Nominal diameter 25mm; Pressure range 0...64bar; Length 82mm; Flange ISO5211 F04; Square 11mm
BA413-100-S0A
Flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to ANSI B16.10; Flange ANSI150; Full bore; Body 1.4408; Ball 1.4401; Seals TFM-MPTFE/Graphoil/V-Pack PTFE; Single acting actuator ATEX II 2 G/D c T6; Control pressure 5,5...8bar; Medium temperature -40...+180°C; Pressure range 0...20bar; Nominal diameter 100mm; Length 229mm; Actuator PAS1255
BA413-150-S0-A
Flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to ANSI B16.10; Flange ANSI150; Full bore; Body 1.4408; Ball 1.4401; Seals TFM-MPTFE/Graphoil/V-Pack PTFE; Single acting actuator ATEX II 2 G/D c T6; Control pressure 5,5...8bar; Medium temperature -40...+180°C; Pressure range 0...20bar; Nominal diameter 150mm; Length 394mm; Actuator PAS1805
BA413-25-S0A
Flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to ANSI B16.10; Flange ANSI150; Full bore; Body 1.4408; Ball 1.4401; Seals TFM-MPTFE/Graphoil/V-Pack PTFE; Single acting actuator ATEX II 2 G/D c T6; Control pressure 5,5...8bar; Medium temperature -40...+180°C; Pressure range 0...20bar; Nominal diameter 25mm; Length 127mm; Actuator PAS0635
BA413-50-S0-A
Flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to ANSI B16.10; Flange ANSI150; Full bore; Body 1.4408; Ball 1.4401; Seals TFM-MPTFE/Graphoil/V-Pack PTFE; Single acting actuator ATEX II 2 G/D c T6; Control pressure 5,5...8bar; Medium temperature -40...+180°C; Pressure range 0...20bar; Nominal diameter 50mm; Length 178mm; Actuator PAS1005
BA413-80-S0-A
Flanged ball valve with pneumatic actuator Series BA413-S-A; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to ANSI B16.10; Flange ANSI150; Full bore; Body 1.4408; Ball 1.4401; Seals TFM-MPTFE/Graphoil/V-Pack PTFE; Single acting actuator ATEX II 2 G/D c T6; Control pressure 5,5...8bar; Medium temperature -40...+180°C; Pressure range 0...20bar; Nominal diameter 80mm; Length 203mm; Actuator PAS1255
BA414-100-S0-A
Flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to ANSI B16.10; Flange ANSI600; Full bore; Body, Ball 1.4408; Seals TFM-MPTFE/Graphoil/V-Pack PTFE; Single acting actuator ATEX II 2 G/D c T6; Control pressure 5,5...8bar; Medium temperature -40...+180°C; Pressure range 0...100bar; Nominal diameter 100mm; Length 432mm; Actuator PAS1805
BA414-50-S0-A
Flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to ANSI B16.10; Flange ANSI600; Full bore; Body, Ball 1.4408; Seals TFM-MPTFE/Graphoil/V-Pack PTFE; Single acting actuator ATEX II 2 G/D c T6; Control pressure 5,5...8bar; Medium temperature -40...+180°C; Pressure range 0...100bar; Nominal diameter 50mm; Length 292mm; Actuator PAS1155
BA414-80-S0-A
Flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; Fire-safe; TA-Luft; Length According to ANSI B16.10; Flange ANSI600; Full bore; Body, Ball 1.4408; Seals TFM-MPTFE/Graphoil/V-Pack PTFE; Single acting actuator ATEX II 2 G/D c T6; Control pressure 5,5...8bar; Medium temperature -40...+180°C; Pressure range 0...100bar; Nominal diameter 80mm; Length 356mm; Actuator PAS1605
BA431-12-S0-0-01
ball valve with pneumatic actuator; free of oil and grease; female thread; housing, ball AISI 316; seals PTFE/FFKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; RP 1/2"; nominal diameter 15mm; pressure range 0-16bar; length 66mm; actuator PAS0635
BA431-12-S0-01
ball valve with pneumatic actuator; female thread; housing, ball AISI 316; seals PTFE/FFKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; RP 1/2"; nominal diameter 15mm; pressure range 0-16bar; length 66mm; actuator PAS0635
BA436-12-B
ball valve made of stainless steel; bare shaft; 3-way-type; female thread; full bore; housing AISI 316L polished; ball AISI 316L; seals PTFE-metal reinforced/FKM; sealing on three ports; medium temperature -20...+200°C; G 1/2"; nominal diameter 15mm; pressure range 0...100bar; length 82mm; ball L; flange ISO5211 F03; square 9mm; incl. heating jacket
BA437-14N-T5-01
Ball valve with pneumatic actuator; Female thread; Body 1.4571; Ball 1.3964; Seals PEEK/FKM-Special; Free of oil and grease; Single acting actuator; Control pressure 6...8bar; Medium temperature -40...+85°C; Ambient temperature -40...+70°C; Connection 1/4"NPT; Nominal diameter 8mm; Pressure range 0...650bar; Safety position NO
BA437-14N-T5-02
Ball valve with pneumatic actuator; Female thread; Body 1.4571; Ball 1.3964; Seals PEEK/FKM-Special; Free of oil and grease; Single acting actuator; Control pressure 6...8bar; Medium temperature -40...+200°C; Ambient temperature -40...+200°C; Connection 1/4"NPT; Nominal diameter 8mm; Pressure range 0...650bar; Safety position NO
BA437-14N-T5-3C-02
Ball valve with pneumatic actuator; Female thread; Body 1.4571; Ball Nitronic-50; Seals PEEK/FKM-Special; Single acting actuator; Control pressure 6...8bar; Medium temperature -40...+200°C; Ambient temperature -40...+200°C; 1/4"-NPT; Nominal diameter 8mm; Pressure range 0...650bar; Safety position NO; Free of oil and grease; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness; Additional High pressure gas test
BA437-38N-S0-01
ball valve with pneumatic actuator; female thread; housing AISI 316Ti; ball 1.3964; seals PEEK/FKM-special; with erosion protection ring; free of oil and grease; single acting actuator; control pressure 5,5...8bar; medium temperature -40...+200°C; for gases; connection 3/8"NPT; nominal diameter 13mm; pressure range 0...650bar; actuator PAS1155
BA438-150-B
Flanged ball valve with bare shaft; Flange PN100, Full bore; Body, Ball 1.4571; Seals POM/NBR; Pressure range 0...100bar; Medium temperature -20...+50°C; Nominal diameter 150mm; F14/SW36; 880Nm
