Cylinders

PC49-32-2000

Rodless magnetic cylinder; Double acting; Pressure range 0,5...8bar; Adjustable cushions; Diameter 32mm; Stroke 2000mm; Connection 1/4"; Push force at 6 bar 420N; Max. load L 495N

Tie-rod magnetic cylinder; According to ISO 15552, VDMA; Double acting; Pressure range 0,5...10bar; Adjustable cushions; Diameter 200mm; Stroke 400mm; Piston rod thread M36x2; Connection 3/4"; Push force at 6 bar 18840N; Seals made of FKM

XJSS63-80-VV

Tie-rod magnetic cylinder; According to ISO 15552, VDMA; Double acting; Pressure range 0,5...10bar; Adjustable cushions; Completely made of stainless steel 1.4301; All seals FKM; Diameter 63mm; Stroke 80mm; Piston rod thread M16x1,5; Connection 3/8"; Push force at 6 bar 1869N

SHD200-70

Compact cylinder; Double acting; Pressure range 1...10bar; Diameter 200mm; Stroke 70mm; Piston rod thread M20; Connection 3/8"; Push force at 6 bar 18840N

PC31-63-80-VVE45

PS-PM-25-200-CD

pneumatic slide unit double-acting, diameter 25mm, stroke 200mm with 2 shock absorbers, high-precision ball bearing

XJSS63-320

Tie-rod magnetic cylinder; According to ISO 15552, VDMA; Double acting; Pressure range 0,5...10bar; Adjustable cushions; Completely made of stainless steel 1.4301; Rod seal FKM; Rest PU; Diameter 63mm; Stroke 320mm; Piston rod thread M16x1,5; Connection 3/8"; Push force at 6 bar 1869N

PC26-16-500-1W

Rodless magnetic cylinder With ball bearing guide; Double acting; Seals NBR; Pressure range 0,5...8bar; Adjustable cushions; Diameter 16mm; Stroke 500mm; Connection 1/4"; Push force at 6 bar 110N; Max. load L 500N; Quantity Guides Lateral 1

HNG32-200-BB

Compact-section tube magnetic guide cylinder; Double acting; Pressure Max. 10bar; Diameter 32mm; Stroke 200mm; Connection 1/8"; Push force at 6 bar 482N; Guide-bearing Ball bushing

PC23-63-700

Rodless magnetic cylinder; Double acting; Pressure range 0,5...8bar; Adjustable cushions; Diameter 63mm; Stroke 700mm; Connection 3/8"; Push force at 6 bar 1550N; Max. load L 1650N

PC11-200-410

Tie-rod magnetic cylinder; According to ISO 15552, VDMA; Double acting; Pressure range 0,5...10bar; Adjustable cushions; Diameter 200mm; Stroke 410mm; Piston rod thread M36x2; Connection 3/4"; Push force at 6 bar 18840N

F3-01-400

Hydraulic cushioning cylinder; Speed control Moving out; Bowl Parallel; Diameter 35mm; Stroke 300mm

HNG63-200-BS

Compact-section tube magnetic guide cylinder; Double acting; Pressure Max. 10bar; Diameter 63mm; Stroke 200mm; Connection 1/4"; Push force at 6 bar 1869N; Guide-bearing Brass

PC43-160-500-VV-01

Tie-rod magnetic cylinder; According to ISO 15552, VDMA; Double acting; Pressure range 0,5...10bar; Adjustable cushions; Diameter 160mm; Stroke 500mm; Connection 3/4"; Push force at 6 bar 12057N; Seals made of FKM; 408mm Extended piston rod; C=488mm; Piston rod thread M16 Female thread; Thread depth 32mm

PC43-160-1000-05

Tie-rod magnetic cylinder; According to ISO 15552, VDMA; Double acting; Pressure range 0,5...10bar; Adjustable cushions; Diameter 160mm; Stroke 1000mm; Piston rod thread M36x2; Connection 3/4"; Rod seal E8; Piston-rod Stainless steel; Push force at 6 bar 12057N; Piston rod extension by 348mm

PLR25.1/25-1020

Rodless magnetic cylinder; Double acting; Pressure range 0,5...8bar; Diameter 25mm; Stroke 1020mm; Connection 1/8"; Push force at 6 bar 250N; Max. load L 1400N

XJS100-250

Tie-rod magnetic cylinder; According to ISO 15552, VDMA; Double acting; Pressure range 0,5...10bar; Adjustable cushions; End And Cover Acetal polymer; Cylinder tube 1.4301; Diameter 100mm; Stroke 250mm; Piston rod thread M20x1,5; Connection 1/2"; Push force at 6 bar 4710N

PC15-50-200-BB

Compact-section tube magnetic guide cylinder; Double acting; Pressure Max. 10bar; Diameter 50mm; Stroke 200mm; Connection 1/4"; Push force at 6 bar 1178N; Guide-bearing Ball bushing
